Posted on September 17, 2024September 18, 2024 by Dale Phillips Fall Collection 2024 Articles Online Fall Collection 2024 GAL Members – Login first before clicking on article titles to read the full articles. Not a 2024 member? You can join or renew here. Radiation from Lower Guitar Modes by Graham Caldersmith (1985) Caldersmith discusses the efficiency and pattern of sound radiation in the classic guitar produced by the four lower resonance modes, which he calls monopole, cross dipole, long dipole, and tripole. Inside Pacific Rim Tonewoods by Steve McMinn (1993) McMinn’s lutherie wood business has turned out to be a pretty big deal. Here we gain perspective by seeing it at the very beginning. The Great White Sitka by Jeffrey R. Elliott (1993) Holy Moby Spruce! How does one hack a log that’s eleven feet wide into 4000 guitar tops? Very carefully! By the way, this is a log that Steve McMinn rescued from the pulp mill. Meet the Maker: Bernard Millant by Jonathon Peterson (2006) Millant is a violin maker, a bow maker, an appraiser, an author, and a man of high repute within the violin world. The depth of training behind many old-school fiddle people will astonish most guitar makers, and it makes for entrancing reading. Meet the Maker: Dmitry Zhevlakov by Federico Sheppard (2007) This is not only the story of a Russian luthier who also makes beautiful rosettes for other builders, but is another example of how the Internet has changed the world — in this case for better. Aluminum Sonatas: A Brief History of Aluminum Stringed Instruments in the Last 120 Years by James Condino (2007) Every luthier knows how fickle and finicky the market is, so it’s no wonder that musical instruments made of aluminum didn’t catch on. Examined here are a violin, a mandolin, and a pair of bass viols. Fun stuff! Mechanical Compliance for Soundboard Optimization by David Hurd (2007) Hurd believes that the fastest way to great instruments is science, and it’s hard to argue with such a rational man. His jigs measure the deflection of top plates while under tension, and once he carves the top and braces to the numbers he wants, he’s done. This could be math heavy, but he offers an Internet spread sheet to ease the pain. Construction of the Colombian Tiple by Anamaria Paredes Garcia and R.M. Mottola (2007) Cross a 12-string flattop with a classical guitar and you get the Colombian tiple. The tiple has four courses of three steel strings, but on the inside, it’s a classical. Follow Alberto Paredes as he builds the instrument in this photo tour. See GAL Plan #51. Meet the Maker: Mervyn Davis by Rodney Stedall (2007) Davis’ South African upbringing inspires a wonderful decorative sense in his instruments. He’s built a ton of different stuff but may end up best known for his wildly unique modular guitars called Smooth Talkers. Cricket: A Reclaimed Salvage Recovery by James Condino (2007) Condino’s mandolin is made from recycled materials, mostly Douglas fir and katalox. It is unique and beautiful, and the story behind it is pretty cool, too. Grading on the Curves: Fitting Bars and Bridges on Archtop Guitars by Steve Andersen (2007) This is a very detailed look at how a notable builder of archtop guitars fits tone bars and bridges to his instruments. The Venezuelan Cuatro by Aquiles Torres (2008) Traditionally, this instrument is a small 4-string guitar with 14 frets clear, no frets over the body, a flush fretboard, and a large veneer tap plate. Note that the cuatro built for the article has 17 frets clear of the body. See GAL Plan #58. The MacRostie Mandolin Deflection Jig by Don MacRostie (2008) MacRostie’s clever jig measures the top deflection of a carved mandolin under string load at any stage of its construction. It is a valuable tool within the reach of any luthier. The “Corker” Guitar: A Sideport Experiment by Alan Carruth (2008) Carruth built a classical guitar with many small ports drilled in the side. By plugging the ports in various combinations he investigated the usefulness and physics behind them. Though this guitar did not make a believer out of him, he admits that his results are somewhat inconclusive. Electric Guitar Setup by Erick Coleman and Elliot John-Conry (2009) Two disciples of Dan Erlewine explain the latest techniques of setting up the electric guitar. All the details and specs are there, as well as a bit of philosophy. Dulcimer 101 by John Calkin (2009) Dulcimers are needlessly maligned and in need of advocates, and the author is a strong one. Tools and jiggery are kept to a minimum to make construction of this entry level instrument as accessible as possible. The Guitar as a Structure and Some Practical Information on Bracing by James Blilie (2009) A structural engineer and guitar builder sees the guitar as a thing buffeted by forces and stresses. Total Flame Out: Retopping a Harp Guitar by Harry Fleishman (2009) Harry replaces the failed soundboard on a complicated instrument with as little refinishing and other stress as possible. Strings: The (Often) Forgotten Accessory by Fan Tao (2010) D’Addario's resident scientist Fan Tao helps us understand string issues in relation to custom instruments and customized tuning. Practical Acoustics by Michael Cone (2010) Cone describes his advanced apparatus and method for acoustically testing classical guitars. Meet the Maker: James Ham by Roger Alan Skipper (2010) Ham operates from a shop in Victoria, B.C. where he repairs and restores violin family instruments and constructs world class double basses. It’s All About the Core or How to Estimate Compensation by Sjaak Elmendorp (2010) Mathematics and parameters used to address the problem of string compensation estimation. Articles Online Fall Collection 2024 Radiation from Lower Guitar Modes by Graham Caldersmith (1985) Caldersmith discusses the efficiency and pattern of sound radiation in the classic guitar produced by the four lower resonance modes, which he calls monopole, cross dipole, long dipole, and tripole. Inside Pacific Rim Tonewoods by Steve McMinn (1993) McMinn's lutherie wood business has turned out to be a pretty big deal. Here we gain perspective by seeing it at the very beginning. The Great White Sitka by Jeffrey R. Elliott (1993) Holy Moby Spruce! How does one hack a log that’s eleven feet wide into 4000 guitar tops? Very carefully! By the way, this is a log that Steve McMinn rescued from the pulp mill. Meet the Maker: Bernard Millant by Jonathon Peterson (2006) Millant is a violin maker, a bow maker, an appraiser, an author, and a man of high repute within the violin world. The depth of training behind many old-school fiddle people will astonish most guitar makers, and it makes for entrancing reading. Meet the Maker: Dmitry Zhevlakov by Federico Sheppard (2007) This is not only the story of a Russian luthier who also makes beautiful rosettes for other builders, but is another example of how the Internet has changed the world — in this case for better. Aluminum Sonatas: A Brief History of Aluminum Stringed Instruments in the Last 120 Years by James Condino (2007) Every luthier knows how fickle and finicky the market is, so it’s no wonder that musical instruments made of aluminum didn’t catch on. Examined here are a violin, a mandolin, and a pair of bass viols. Fun stuff! Mechanical Compliance for Soundboard Optimization by David Hurd (2007) Hurd believes that the fastest way to great instruments is science, and it’s hard to argue with such a rational man. His jigs measure the deflection of top plates while under tension, and once he carves the top and braces to the numbers he wants, he’s done. This could be math heavy, but he offers an Internet spread sheet to ease the pain. Construction of the Colombian Tiple by Anamaria Paredes Garcia and R.M. Mottola (2007) Cross a 12-string flattop with a classical guitar and you get the Colombian tiple. The tiple has four courses of three steel strings, but on the inside, it’s a classical. Follow Alberto Paredes as he builds the instrument in this photo tour. See GAL Plan #51. Meet the Maker: Mervyn Davis by Rodney Stedall (2007) Davis’ South African upbringing inspires a wonderful decorative sense in his instruments. He’s built a ton of different stuff but may end up best known for his wildly unique modular guitars called Smooth Talkers. Cricket: A Reclaimed Salvage Recovery by James Condino (2007) Condino’s mandolin is made from recycled materials, mostly Douglas fir and katalox. It is unique and beautiful, and the story behind it is pretty cool, too. Grading on the Curves: Fitting Bars and Bridges on Archtop Guitars by Steve Andersen (2007) This is a very detailed look at how a notable builder of archtop guitars fits tone bars and bridges to his instruments. The Venezuelan Cuatro by Aquiles Torres (2008) Traditionally, this instrument is a small 4-string guitar with 14 frets clear, no frets over the body, a flush fretboard, and a large veneer tap plate. Note that the cuatro built for the article has 17 frets clear of the body. See GAL Plan #58. The MacRostie Mandolin Deflection Jig by Don MacRostie (2008) MacRostie’s clever jig measures the top deflection of a carved mandolin under string load at any stage of its construction. It is a valuable tool within the reach of any luthier. The “Corker” Guitar: A Sideport Experiment by Alan Carruth (2008) Carruth built a classical guitar with many small ports drilled in the side. By plugging the ports in various combinations he investigated the usefulness and physics behind them. Though this guitar did not make a believer out of him, he admits that his results are somewhat inconclusive. Electric Guitar Setup by Erick Coleman and Elliot John-Conry (2009) Two disciples of Dan Erlewine explain the latest techniques of setting up the electric guitar. All the details and specs are there, as well as a bit of philosophy. Dulcimer 101 by John Calkin (2009) Dulcimers are needlessly maligned and in need of advocates, and the author is a strong one. Tools and jiggery are kept to a minimum to make construction of this entry level instrument as accessible as possible. The Guitar as a Structure and Some Practical Information on Bracing by James Blilie (2009) A structural engineer and guitar builder sees the guitar as a thing buffeted by forces and stresses. Total Flame Out: Retopping a Harp Guitar by Harry Fleishman (2009) Harry replaces the failed soundboard on a complicated instrument with as little refinishing and other stress as possible. Strings: The (Often) Forgotten Accessory by Fan Tao (2010) D'Addario's resident scientist Fan Tao helps us understand string issues in relation to custom instruments and customized tuning. Practical Acoustics by Michael Cone (2010) Cone describes his advanced apparatus and method for acoustically testing classical guitars. Meet the Maker: James Ham by Roger Alan Skipper (2010) Ham operates from a shop in Victoria, B.C. where he repairs and restores violin family instruments and constructs world class double basses. It’s All About the Core or How to Estimate Compensation by Sjaak Elmendorp (2010) Mathematics and parameters used to address the problem of string compensation estimation.
Posted on July 8, 2024October 1, 2024 by Dale Phillips Parametric Solid Modeling Software for Stringed Instrument Design Parametric Solid Modeling Software for Stringed Instrument Design by R.M. Mottola Originally published in American Lutherie #87, 2006 Most folks are awed when first witnessing a Computer Numerical Control (CNC) machine shaping an instrument part. Since such a demonstration makes the advantages of using this technology immediately obvious, a number of people look into acquiring these tools for their own use. A substantial portion quickly loses interest when finding out the depth of complexity of the tools needed to design and build in this manner. Computer Aided Design (CAD) software must be mastered in order to draw the parts. Computer Aided Manufacturing (CAM) software must be mastered in order to specify how the drawings will be utilized in the machining process and to control the CNC machine. And the details of the CNC machine itself must be comprehended before real work can be performed. All of this conspires to lead all but the highly technical and/or highly motivated to the conclusion that these technologies need to be made a lot simpler and more accessible before they can be widely exploited in the industry. Adaptation and use of these technologies can be considered analogous to that of the automobile. When first introduced, the car was something only accessible to those who could understand all of the details of the machine (and repair all the parts, too), but eventually it evolved into a more commodity-like device that is usable with little or no knowledge of its inner workings. This article is an introduction to Parametric Solid Modeling (PSM), an existing second-generation CAD technology that offers potential to bring the benefits of CAD/CAM/CNC to a wider user base. A comprehensive library of parametric models of instrument parts and subassemblies could go a long way toward making these technologies generally accessible. The availability of such a library could render a number of aspects of instrument design to sequences of preparing simple drawings and filling in values in forms. No such library currently exists, but it is possible and likely that one could be developed. Folks working with PSM software in this industry undoubtedly have developed such models for their own use. I have some of my own and will use one as an example of how this technology works. Become A Member to Continue Reading This Article This article is part of the Articles Online featured on our website for Guild members. To view this and other web articles, join the Guild of American Luthiers. Members also receive 3 annual issues of American Lutherie and get discounts on products. For details, visit the membership page. MEMBERS: login for access or contact us to setup your account.
Posted on July 7, 2024October 1, 2024 by Dale Phillips Questions: Martin Finish Questions: Martin finish by Walter Carter Originally published in American Lutherie #104, 2010 Kerry Char from Portland, Oregon asks: Exactly what kind of finish were Gibson and Martin using before they switched to nitrocellulose lacquer? How was it applied, and when was the switch. I’m thinking that it was oil varnish similar to violin varnish, because it is resistant to acetone. But if that’s the case, how did Gibson do some of their sunbursts? I know that the earlier ones were rubbed, but later ones from the ’20s and ’30s look sprayed. Walter Carter from Nashville, Tennessee replies: Neither Gibson nor Martin made an across-the-line change from varnish to lacquer. Richard Johnston and Dick Boak note in their recent book, Martin Guitars: A Technical Reference, that Martin finishes were French polish (shellac) until 1918, when they began experimenting with different combinations of varnish and lacquer. Martin first used nitrocellulose lacquer in 1926, and by 1929 it was the standard finish on most Martin guitars. For Gibsons, Stephen Gilchrist offers this information: Become A Member to Continue Reading This Article This article is part of the Articles Online featured on our website for Guild members. To view this and other web articles, join the Guild of American Luthiers. Members also receive 3 annual issues of American Lutherie and get discounts on products. For details, visit the membership page. MEMBERS: login for access or contact us to setup your account.
Posted on July 7, 2024July 9, 2024 by Dale Phillips Questions: Martin Style 5-18 Questions: Martin Style 5-18 by R.J. Klimpert Originally published in American Lutherie #103, 2010 Larry Crozier from the Internet asks: A customer wants a Martin-style 5-18 guitar built. I was wondering if GAL Plan #8 for the Martin 1-18 is the same or close enough. If not, could you recommend somewhere to get a 5-18 plan? R.J. Klimpert of Barrington, Rhode Island responds: The chief reason that the 1-18 pattern won’t work to build a 5-18 is that the Martin 5-18 is a “terz” guitar, meaning that the neck and scale length are considerably shorter than that of a regular Martin, allowing for the higher-than-standard tuning that terz guitars are known for. The 1-18’s body, while narrow and seemingly similar in size to a 5-18, is too long to allow for a terz short-scale neck. The 5-18 is actually closer to a Martin Style 51 baritone uke in body size and scale. In fact, Martin reportedly reused an old terz guitar pattern when they started producing the 10-string tiple in the late ’teens. As for finding a pattern that would work for building a 5-18, it might be possible to reduce the dimensions of a 000-18 — all except the width of the neck — to approximate the correct size and shape. Or conversely, scale UP the dimensions of a Martin tiple (GAL Plan #37), since the 5-18 terz guitar lies somewhere between the two. ◆
Posted on July 7, 2024October 1, 2024 by Dale Phillips Questions: J-45 Body Questions: J-45 Body by Joe Veillette Originally published in American Lutherie #102, 2010 David Brooks from Tucson, Arizona asks: I want to build a 12-string guitar based on a J-45 body or similar. What changes to the 6-string version of the J-45 do I need to make to handle the additional tension? Joe Veillette from Woodstock, New York responds: In my experience there are two ways to go. If your idea of a 12-string is what most people are used to (25"–25 5/8" scale), I feel that all you have to do is add about 10% to the cross-sectional dimensions of what you’d use for normal 6-string top bracing. The top thickness as well as the back and sides can remain unchanged. This “normal” 12-string should be tuned down a step to D (many old Guilds came that way), or strung with extra-light strings due to the high tension of the octave strings which otherwise tend to be harder to play, more finicky in terms of intonation, and can often deform the top. Of course this isn’t always the case, but it’s close. In my opinion, both detuning and the use of really light strings are unfortunate compromises. But some people prefer the lower tuning and there’s nothing wrong with it if that’s what you like. Become A Member to Continue Reading This Article This article is part of the Articles Online featured on our website for Guild members. To view this and other web articles, join the Guild of American Luthiers. Members also receive 3 annual issues of American Lutherie and get discounts on products. For details, visit the membership page. MEMBERS: login for access or contact us to setup your account.
