Posted on September 17, 2024September 18, 2024 by Dale Phillips Fall Collection 2024 Articles Online Fall Collection 2024 GAL Members – Login first before clicking on article titles to read the full articles. Not a 2024 member? You can join or renew here. Radiation from Lower Guitar Modes by Graham Caldersmith (1985) Caldersmith discusses the efficiency and pattern of sound radiation in the classic guitar produced by the four lower resonance modes, which he calls monopole, cross dipole, long dipole, and tripole. Inside Pacific Rim Tonewoods by Steve McMinn (1993) McMinn’s lutherie wood business has turned out to be a pretty big deal. Here we gain perspective by seeing it at the very beginning. The Great White Sitka by Jeffrey R. Elliott (1993) Holy Moby Spruce! How does one hack a log that’s eleven feet wide into 4000 guitar tops? Very carefully! By the way, this is a log that Steve McMinn rescued from the pulp mill. Meet the Maker: Bernard Millant by Jonathon Peterson (2006) Millant is a violin maker, a bow maker, an appraiser, an author, and a man of high repute within the violin world. The depth of training behind many old-school fiddle people will astonish most guitar makers, and it makes for entrancing reading. Meet the Maker: Dmitry Zhevlakov by Federico Sheppard (2007) This is not only the story of a Russian luthier who also makes beautiful rosettes for other builders, but is another example of how the Internet has changed the world — in this case for better. Aluminum Sonatas: A Brief History of Aluminum Stringed Instruments in the Last 120 Years by James Condino (2007) Every luthier knows how fickle and finicky the market is, so it’s no wonder that musical instruments made of aluminum didn’t catch on. Examined here are a violin, a mandolin, and a pair of bass viols. Fun stuff! Mechanical Compliance for Soundboard Optimization by David Hurd (2007) Hurd believes that the fastest way to great instruments is science, and it’s hard to argue with such a rational man. His jigs measure the deflection of top plates while under tension, and once he carves the top and braces to the numbers he wants, he’s done. This could be math heavy, but he offers an Internet spread sheet to ease the pain. Construction of the Colombian Tiple by Anamaria Paredes Garcia and R.M. Mottola (2007) Cross a 12-string flattop with a classical guitar and you get the Colombian tiple. The tiple has four courses of three steel strings, but on the inside, it’s a classical. Follow Alberto Paredes as he builds the instrument in this photo tour. See GAL Plan #51. Meet the Maker: Mervyn Davis by Rodney Stedall (2007) Davis’ South African upbringing inspires a wonderful decorative sense in his instruments. He’s built a ton of different stuff but may end up best known for his wildly unique modular guitars called Smooth Talkers. Cricket: A Reclaimed Salvage Recovery by James Condino (2007) Condino’s mandolin is made from recycled materials, mostly Douglas fir and katalox. It is unique and beautiful, and the story behind it is pretty cool, too. Grading on the Curves: Fitting Bars and Bridges on Archtop Guitars by Steve Andersen (2007) This is a very detailed look at how a notable builder of archtop guitars fits tone bars and bridges to his instruments. The Venezuelan Cuatro by Aquiles Torres (2008) Traditionally, this instrument is a small 4-string guitar with 14 frets clear, no frets over the body, a flush fretboard, and a large veneer tap plate. Note that the cuatro built for the article has 17 frets clear of the body. See GAL Plan #58. The MacRostie Mandolin Deflection Jig by Don MacRostie (2008) MacRostie’s clever jig measures the top deflection of a carved mandolin under string load at any stage of its construction. It is a valuable tool within the reach of any luthier. The “Corker” Guitar: A Sideport Experiment by Alan Carruth (2008) Carruth built a classical guitar with many small ports drilled in the side. By plugging the ports in various combinations he investigated the usefulness and physics behind them. Though this guitar did not make a believer out of him, he admits that his results are somewhat inconclusive. Electric Guitar Setup by Erick Coleman and Elliot John-Conry (2009) Two disciples of Dan Erlewine explain the latest techniques of setting up the electric guitar. All the details and specs are there, as well as a bit of philosophy. Dulcimer 101 by John Calkin (2009) Dulcimers are needlessly maligned and in need of advocates, and the author is a strong one. Tools and jiggery are kept to a minimum to make construction of this entry level instrument as accessible as possible. The Guitar as a Structure and Some Practical Information on Bracing by James Blilie (2009) A structural engineer and guitar builder sees the guitar as a thing buffeted by forces and stresses. Total Flame Out: Retopping a Harp Guitar by Harry Fleishman (2009) Harry replaces the failed soundboard on a complicated instrument with as little refinishing and other stress as possible. Strings: The (Often) Forgotten Accessory by Fan Tao (2010) D’Addario's resident scientist Fan Tao helps us understand string issues in relation to custom instruments and customized tuning. Practical Acoustics by Michael Cone (2010) Cone describes his advanced apparatus and method for acoustically testing classical guitars. Meet the Maker: James Ham by Roger Alan Skipper (2010) Ham operates from a shop in Victoria, B.C. where he repairs and restores violin family instruments and constructs world class double basses. It’s All About the Core or How to Estimate Compensation by Sjaak Elmendorp (2010) Mathematics and parameters used to address the problem of string compensation estimation. Articles Online Fall Collection 2024 Radiation from Lower Guitar Modes by Graham Caldersmith (1985) Caldersmith discusses the efficiency and pattern of sound radiation in the classic guitar produced by the four lower resonance modes, which he calls monopole, cross dipole, long dipole, and tripole. Inside Pacific Rim Tonewoods by Steve McMinn (1993) McMinn's lutherie wood business has turned out to be a pretty big deal. Here we gain perspective by seeing it at the very beginning. The Great White Sitka by Jeffrey R. Elliott (1993) Holy Moby Spruce! How does one hack a log that’s eleven feet wide into 4000 guitar tops? Very carefully! By the way, this is a log that Steve McMinn rescued from the pulp mill. Meet the Maker: Bernard Millant by Jonathon Peterson (2006) Millant is a violin maker, a bow maker, an appraiser, an author, and a man of high repute within the violin world. The depth of training behind many old-school fiddle people will astonish most guitar makers, and it makes for entrancing reading. Meet the Maker: Dmitry Zhevlakov by Federico Sheppard (2007) This is not only the story of a Russian luthier who also makes beautiful rosettes for other builders, but is another example of how the Internet has changed the world — in this case for better. Aluminum Sonatas: A Brief History of Aluminum Stringed Instruments in the Last 120 Years by James Condino (2007) Every luthier knows how fickle and finicky the market is, so it’s no wonder that musical instruments made of aluminum didn’t catch on. Examined here are a violin, a mandolin, and a pair of bass viols. Fun stuff! Mechanical Compliance for Soundboard Optimization by David Hurd (2007) Hurd believes that the fastest way to great instruments is science, and it’s hard to argue with such a rational man. His jigs measure the deflection of top plates while under tension, and once he carves the top and braces to the numbers he wants, he’s done. This could be math heavy, but he offers an Internet spread sheet to ease the pain. Construction of the Colombian Tiple by Anamaria Paredes Garcia and R.M. Mottola (2007) Cross a 12-string flattop with a classical guitar and you get the Colombian tiple. The tiple has four courses of three steel strings, but on the inside, it’s a classical. Follow Alberto Paredes as he builds the instrument in this photo tour. See GAL Plan #51. Meet the Maker: Mervyn Davis by Rodney Stedall (2007) Davis’ South African upbringing inspires a wonderful decorative sense in his instruments. He’s built a ton of different stuff but may end up best known for his wildly unique modular guitars called Smooth Talkers. Cricket: A Reclaimed Salvage Recovery by James Condino (2007) Condino’s mandolin is made from recycled materials, mostly Douglas fir and katalox. It is unique and beautiful, and the story behind it is pretty cool, too. Grading on the Curves: Fitting Bars and Bridges on Archtop Guitars by Steve Andersen (2007) This is a very detailed look at how a notable builder of archtop guitars fits tone bars and bridges to his instruments. The Venezuelan Cuatro by Aquiles Torres (2008) Traditionally, this instrument is a small 4-string guitar with 14 frets clear, no frets over the body, a flush fretboard, and a large veneer tap plate. Note that the cuatro built for the article has 17 frets clear of the body. See GAL Plan #58. The MacRostie Mandolin Deflection Jig by Don MacRostie (2008) MacRostie’s clever jig measures the top deflection of a carved mandolin under string load at any stage of its construction. It is a valuable tool within the reach of any luthier. The “Corker” Guitar: A Sideport Experiment by Alan Carruth (2008) Carruth built a classical guitar with many small ports drilled in the side. By plugging the ports in various combinations he investigated the usefulness and physics behind them. Though this guitar did not make a believer out of him, he admits that his results are somewhat inconclusive. Electric Guitar Setup by Erick Coleman and Elliot John-Conry (2009) Two disciples of Dan Erlewine explain the latest techniques of setting up the electric guitar. All the details and specs are there, as well as a bit of philosophy. Dulcimer 101 by John Calkin (2009) Dulcimers are needlessly maligned and in need of advocates, and the author is a strong one. Tools and jiggery are kept to a minimum to make construction of this entry level instrument as accessible as possible. The Guitar as a Structure and Some Practical Information on Bracing by James Blilie (2009) A structural engineer and guitar builder sees the guitar as a thing buffeted by forces and stresses. Total Flame Out: Retopping a Harp Guitar by Harry Fleishman (2009) Harry replaces the failed soundboard on a complicated instrument with as little refinishing and other stress as possible. Strings: The (Often) Forgotten Accessory by Fan Tao (2010) D'Addario's resident scientist Fan Tao helps us understand string issues in relation to custom instruments and customized tuning. Practical Acoustics by Michael Cone (2010) Cone describes his advanced apparatus and method for acoustically testing classical guitars. Meet the Maker: James Ham by Roger Alan Skipper (2010) Ham operates from a shop in Victoria, B.C. where he repairs and restores violin family instruments and constructs world class double basses. It’s All About the Core or How to Estimate Compensation by Sjaak Elmendorp (2010) Mathematics and parameters used to address the problem of string compensation estimation.
Posted on July 8, 2024October 1, 2024 by Dale Phillips Parametric Solid Modeling Software for Stringed Instrument Design Parametric Solid Modeling Software for Stringed Instrument Design by R.M. Mottola Originally published in American Lutherie #87, 2006 Most folks are awed when first witnessing a Computer Numerical Control (CNC) machine shaping an instrument part. Since such a demonstration makes the advantages of using this technology immediately obvious, a number of people look into acquiring these tools for their own use. A substantial portion quickly loses interest when finding out the depth of complexity of the tools needed to design and build in this manner. Computer Aided Design (CAD) software must be mastered in order to draw the parts. Computer Aided Manufacturing (CAM) software must be mastered in order to specify how the drawings will be utilized in the machining process and to control the CNC machine. And the details of the CNC machine itself must be comprehended before real work can be performed. All of this conspires to lead all but the highly technical and/or highly motivated to the conclusion that these technologies need to be made a lot simpler and more accessible before they can be widely exploited in the industry. Adaptation and use of these technologies can be considered analogous to that of the automobile. When first introduced, the car was something only accessible to those who could understand all of the details of the machine (and repair all the parts, too), but eventually it evolved into a more commodity-like device that is usable with little or no knowledge of its inner workings. This article is an introduction to Parametric Solid Modeling (PSM), an existing second-generation CAD technology that offers potential to bring the benefits of CAD/CAM/CNC to a wider user base. A comprehensive library of parametric models of instrument parts and subassemblies could go a long way toward making these technologies generally accessible. The availability of such a library could render a number of aspects of instrument design to sequences of preparing simple drawings and filling in values in forms. No such library currently exists, but it is possible and likely that one could be developed. Folks working with PSM software in this industry undoubtedly have developed such models for their own use. I have some of my own and will use one as an example of how this technology works. Become A Member to Continue Reading This Article This article is part of the Articles Online featured on our website for Guild members. To view this and other web articles, join the Guild of American Luthiers. Members also receive 3 annual issues of American Lutherie and get discounts on products. For details, visit the membership page. MEMBERS: login for access or contact us to setup your account.
Posted on July 8, 2024October 1, 2024 by Dale Phillips Post-Toronto Reflections Post-Toronto Reflections by Jeffrey R. Elliott Originally published in Guild of American Luthiers Quarterly 6, #3, 1978 The Canadian-hosted classic guitar festival “Guitar ’78” has left me with several vivid impressions, some of which I felt might merit hearing through the Guild Quarterly. The range and scope of this event was extensive, and to merely remain with the pace was exhausting. While I had hoped to experience something of several other events also scheduled, I soon discovered that to participate in all the luthiers’ happenings meant to forego nearly every other event on the program. With the scheduled four hours of the guitar makers’ workshop each day, meals, the evening concerts, and precious little sleep, any shop talk or visiting with other luthiers meant overlapping with other classes and events. An expected sacrifice from my “Guitar ’75” experience, but extensive and exhausting nonetheless. Of the 600 or so in attendance perhaps 10% were luthiers: having some 60 luthiers around for 24 hours a day, every day for a week, as well as the scheduled 20 hours of lecture-discussion, rendered me totally susceptible and helpless, and I became absorbed in that unique blend of professional and social camaraderie experienced during both the 1977 G.A.L. convention and the “Guitar ’75” festival. Some fine friendships, and solid professional relationships as well, have had their beginnings at these events. The 1978 G.A.L. Convention/Exhibition and the Carmel Classic Guitar Festival ought to round out this year nicely. Become A Member to Continue Reading This Article This article is part of the Articles Online featured on our website for Guild members. To view this and other web articles, join the Guild of American Luthiers. Members also receive 3 annual issues of American Lutherie and get discounts on products. For details, visit the membership page. MEMBERS: login for access or contact us to setup your account.
Posted on July 7, 2024October 2, 2024 by Dale Phillips Questions: Unified Repair Pricing Questions: Unified Repair Pricing Originally published in American Lutherie #25, 1991 John Kitakis from Hendersonville, NC writes: I’ve enjoyed toying with the idea of unified repair pricing throughout North America. To me, it seems unprofessional to have a wide variety of charges for the same repair. I suppose everyone has different needs and wants, and overheads vary, so this “discrepancy” may never be resolved. The repairman down the road (who says he doesn’t need much) will continue to charge $100 for a fret job, and $20 to reglue the bridge. I continue to have plenty of business, so I’ll continue to charge more. Below is a list of a few prices. My complete list is available upon request. Become A Member to Continue Reading This Article This article is part of the Articles Online featured on our website for Guild members. To view this and other web articles, join the Guild of American Luthiers. Members also receive 3 annual issues of American Lutherie and get discounts on products. For details, visit the membership page. MEMBERS: login for access or contact us to setup your account.
Posted on July 1, 2024July 9, 2024 by Dale Phillips Letter: Romanillos Seminar Letter: Romanillos Seminar by Stephen Frith Originally published in American Lutherie #68, 2001 Dear Tim, I joined the GAL a couple years ago, and this philosophy of openness, sharing, and frank exchange is right on the ball. I saw a free ad in American Lutherie: “Master-classes in Spain, make a guitar with José and Liam Romanillos.” A chance of a lifetime? The Romanillos family hosted a fortnight working holiday, which was busy, friendly, happy, and constructive. Set in the Sigüenze hillsides, we were the comfortable guests of the Hermanos Maristas. In the spirit of openness and sharing, José and Liam helped us consider each piece of wood, as we made our guitars. A quote: “If we know, we tell you.” Based on José‘s first successful instrument in the Spanish tradition of Torres, our work was guided with strategies and beliefs. Secrets don’t exist in good news. On the front bench were all the planning forms and construction templates needed to make a Romanillos and Son guitar, and copying of these was firmly encouraged. The method was straightforward, sensible, and uncomplicated, one that can be easily replicated in my own workshop. I’ve brought home my own Frith/Romanillos. Sounds great! Speaking as an old London College of Furniture boy, I have to say the Sigüenza 2001 course was brilliant. The cost was reasonable, and returning next year for some fine-tuning would be exciting for a full-time luthier like me. I hope it runs and runs, there is always more to learn. It was great to meet members from all over: Texas, California, Canada, England, Switzerland, Germany, Belgium, Spain, and Japan. Sigüenza 2002? Go for it! ◆
